Fast Point Transformer

Chunghyun ParkYoonwoo JeongMinsu ChoJaesik Park

article2022CVPR252 citations

Proposes a lightweight local self-attention architecture with centroid-aware voxelization and hashing that encodes continuous 3D coordinates to process large-scale point clouds over a hundred times faster than standard point transformers.

Listen

Interpreting large-scale 3D sensor data quickly and accurately is essential for emerging technologies such as autonomous robotics, augmented reality, and intelligent spatial agents. Traditional deep learning frameworks face severe bottlenecks: point-based models achieve high accuracy but require slow, computationally heavy neighbor searches and multi-stage stitching, whereas voxel-based models operate rapidly on regular spatial grids but lose fine geometric details due to quantization errors. Developing a 3D vision pipeline that balances real-time processing speed with fine-grained accuracy has remained a persistent industry challenge.

The article demonstrates the effectiveness of Fast Point Transformer, a lightweight 3D deep learning architecture designed to process large point clouds rapidly while preserving continuous geometric coordinate information. The researchers evaluate this approach across standard 3D semantic segmentation and 3D object detection benchmarks (S3DIS and ScanNet), assessing inference latency, segmentation accuracy, detection precision, and geometric consistency under spatial rotations and translations.

The proposed method bridges the gap between point and voxel representations through three core techniques: centroid-aware voxelization and devoxelization that encode continuous relative positions to prevent quantization loss, a decomposed lightweight self-attention layer using cosine similarity to minimize memory complexity, and an underlying voxel hashing structure enabling single-shot full-scene inference without expensive neighbor searches.

The experimental findings show substantial operational gains. First, Fast Point Transformer achieves an inference speed of 0.14 seconds per scene on the S3DIS dataset, running 129 times faster than the state-of-the-art Point Transformer baseline and at least 83 times faster than other standard point-based models. Second, it delivers competitive accuracy, achieving a 68.5% mean intersection-over-union on S3DIS (increasing to 70.1% with rotation averaging) and outperforming the leading voxel baseline, MinkowskiNet42. Third, it exhibits exceptional model compactness and resilience; reducing network parameters by up to 71.5% causes negligible accuracy loss (under 0.3 percentage points), unlike voxel convolutional networks that degrade sharply. Fourth, when integrated into 3D object detection frameworks on ScanNet, it outperforms previous point and voxel backbones, raising mean average precision scores significantly. Finally, evaluation via a novel consistency metric confirms the model maintains highly stable predictions regardless of rigid rotations and translations.

These results demonstrate that organizations deploying 3D computer vision do not need to choose between slow, high-accuracy point transformers and fast, error-prone voxel convolutions. Fast Point Transformer lowers computational and memory hardware overheads, unlocking viable single-shot, real-time 3D perception for latency-critical and edge-device applications.

Teams implementing 3D spatial systems should consider adopting lightweight self-attention and centroid-aware hashing mechanisms to reduce inference infrastructure costs. For future development, the authors note that exploring non-convolutional, native transformer network architectures could yield additional accuracy improvements at very fine voxel resolutions.

Pohang University of Science and Technology computational efficiency encoder-decoder hashing Fast Point Transformer large-scale point cloud point cloud processing

arXiv: 2112.04702

Paper: Point Transformer, Nico Engel et al. (2020). Point Transformer introduced attention mechanisms tailored directly for unordered 3D point sets, establishing the foundational architecture and high computational bottlenecks that Fast Point Transformer specifically redesigns for speed.
Paper: PCT: Point cloud transformer, Meng-Hao Guo et al. (2020). This paper establishes key principles of attention and offset-attention architectures on irregular point sets, providing direct context for lightweight transformer design on 3D data.
Paper: 3D Semantic Segmentation with Submanifold Sparse Convolutional Networks, Benjamin Graham et al. (2017). It introduces hash-table-based submanifold sparse convolutions on 3D grids, forming the foundational voxel processing structure that Fast Point Transformer combines with self-attention.
Paper: 4D Spatio-Temporal ConvNets: Minkowski Convolutional Neural Networks, Christopher Choy et al. (2019). This work develops the Minkowski sparse convolutional backbone (MinkowskiNet), which serves as a primary voxel baseline outpaced by Fast Point Transformer.
Paper: PV-RCNN: Point-Voxel Feature Set Abstraction for 3D Object Detection, Shaoshuai Shi et al. (2019). PV-RCNN pioneered hybrid point-voxel feature integration to reconcile point precision with voxel speed, motivating the centroid-aware voxelization strategies explored in the source.
Paper: PointNet: Deep Learning on Point Sets for 3D Classification and Segmentation, Charles R. Qi et al. (2017). PointNet is the seminal deep learning architecture for directly processing unordered 3D point sets with permutation invariance, establishing the core problem space.
Paper: PointNet++: Deep Hierarchical Feature Learning on Point Sets in a Metric Space, Charles R. Qi et al. (2017). PointNet++ establishes hierarchical local feature aggregation across point neighborhoods, highlighting the expensive neighbor query bottlenecks that Fast Point Transformer resolves.
Paper: RandLA-Net: Efficient Semantic Segmentation of Large-Scale Point Clouds, Qingyong Hu et al. (2019). RandLA-Net analyzes computational bottlenecks in large-scale point cloud processing and proposes efficient local spatial encoding schemes.

Paper: Superpoint Transformer for 3D Scene Instance Segmentation, Jiahao Sun et al. (2023). Superpoint Transformer builds upon efficient 3D transformer architectures to perform end-to-end 3D scene instance segmentation without relying on expensive dense grouping operations.
Paper: SCTN: Sparse Convolution-Transformer Network for Scene Flow Estimation, Bing Li et al. (2022). SCTN extends hybrid sparse convolution and point transformer designs to dynamic temporal 3D tasks such as scene flow estimation.
Paper: PointNeXt: Revisiting PointNet++ with Improved Training and Scaling Strategies, Guocheng Qian et al. (2022). PointNeXt investigates modern scaling and optimization recipes across standard 3D point cloud benchmarks like S3DIS and ScanNet.
Paper: DUSt3R: Geometric 3D Vision Made Easy, Shuzhe Wang et al. (2023). DUSt3R extends transformer-based 3D coordinate regression into dense multi-view geometric reconstruction without explicit camera calibration.
Paper: VGGT: Visual Geometry Grounded Transformer, Jianyuan Wang et al. (2025). VGGT scales transformer-driven 3D geometric prediction to end-to-end full scene understanding and feed-forward dense point tracking.

Abstract

The recent success of neural networks enables a better interpretation of 3D point clouds, but processing a large-scale 3D scene remains a challenging problem. Most current approaches divide a large-scale scene into small regions and combine the local predictions together. However, this scheme inevitably involves additional stages for pre- and post-processing and may also degrade the final output due to predictions in a local perspective. This paper introduces Fast Point Transformer that consists of a new lightweight self-attention layer. Our approach encodes continuous 3D coordinates, and the voxel hashing-based architecture boosts computational efficiency. The proposed method is demonstrated with 3D semantic segmentation and 3D detection. The accuracy of our approach is competitive to the best voxel-based method, and our network achieves 129 times faster inference time than the state-of-the-art, Point Transformer, with a reasonable accuracy trade-off in 3D semantic segmentation on S3DIS dataset.

Topics

computational efficiency encoder-decoder hashing inference point cloud semantics trade probabilistic inference

Keywords

Fast Point Transformer large-scale point cloud point cloud processing centroid-aware voxel feature sparse convolution positional encoding fast neighbor search S3DIS dataset object detection

1. Introduction
2. Related Work
3. Fast Point Transformer
3.1. Overview
3.2. Centroid-aware Voxel & Devoxelization
3.3. Lightweight Self-Attention
3.4. Network Architecture
4. Experiments
4.1. Datasets
4.2. Baselines
4.3. Consistency Test
4.4. 3D Semantic Segmentation
4.5. 3D Object Detection
5. Conclusion
References

Knowls

Knowl 1 — Fast Point Transformer Framework for Large-Scale 3D Scene Understanding
model/method
Fast Point Transformer is a 3D scene understanding architecture designed to process large-scale point clouds efficiently in a single-shot feed-forward pass without dividing scenes into small cropped blocks or performing expensive $k$ -nearest neighbor searches. The architecture operates in three successive stages:
1. Centroid-Aware Voxelization: The continuous input point cloud $\mathcal{P}^{\text{in}} = \{(\mathbf{p}_n, \mathbf{i}_n)\}_{n=1}^N$ (with 3D coordinates $\mathbf{p}_n$ and input features $\mathbf{i}_n$ ) is converted into non-empty voxel representations $\mathcal{V} = \{(\mathbf{v}_i, \mathbf{f}_i, \mathbf{c}_i)\}_{i=1}^I$ , where $\mathbf{v}_i \in \mathbb{Z}^3$ is the discrete voxel coordinate, $\mathbf{c}_i \in \mathbb{R}^3$ is the continuous centroid coordinate of the points inside voxel $i$ , and $\mathbf{f}_i$ is the aggregated voxel feature incorporating continuous point-to-centroid positional encodings.
2. Lightweight Self-Attention (LSA) Backbone: Local self-attention layers update voxel features $\mathbf{f}_i$ to $\mathbf{f}'_i$ . Spatial neighbor queries are executed via voxel hashing with $\mathcal{O}(1)$ time complexity per query, replacing $\mathcal{O}(N \log N)$ point-level $k$ -NN search. The network adopts a hierarchical U-Net architecture by integrating LSA layers with voxel downsampling and upsampling operations.
3. Centroid-Aware Devoxelization: The output voxel features $\mathcal{V}' = \{(\mathbf{v}_i, \mathbf{f}'_i, \mathbf{c}_i)\}_{i=1}^I$ are projected back to the original continuous points to produce $\mathcal{P}^{\text{out}} = \{(\mathbf{p}_n, \mathbf{o}_n)\}_{n=1}^N$ , utilizing the continuous centroid-to-point positional encodings to preserve fine geometric detail.
Knowl 2 — Centroid-Aware Voxelization and Devoxelization
model/method
To preserve fine continuous geometric structures and prevent quantization artifacts during voxel grid operations, Fast Point Transformer uses centroid-aware voxelization and devoxelization.

For an input point cloud $\mathcal{P}^{\text{in}} = \{(\mathbf{p}_n, \mathbf{i}_n)\}_{n=1}^N$ , where $\mathbf{p}_n \in \mathbb{R}^3$ is the continuous point coordinate and $\mathbf{i}_n \in \mathbb{R}^{D_{\text{in}}}$ is the raw input feature (e.g., RGB color), points are partitioned into non-empty voxels $i \in \{1, \dots, I\}$ . Let $\mathcal{M}(i)$ be the set of point indices mapped to voxel $i$ , and $\mu(n)$ denote the index of the voxel containing point $n$ . The continuous voxel centroid $\mathbf{c}_i \in \mathbb{R}^3$ is computed as: $\mathbf{c}_i = \frac{1}{|\mathcal{M}(i)|} \sum_{n \in \mathcal{M}(i)} \mathbf{p}_n$

A learnable continuous centroid-to-point positional encoding $\mathbf{e}_n \in \mathbb{R}^{D_{\text{enc}}}$ is computed using an encoding layer $\delta_{\text{enc}} : \mathbb{R}^3 \to \mathbb{R}^{D_{\text{enc}}}$ : $\mathbf{e}_n = \delta_{\text{enc}}(\mathbf{p}_n - \mathbf{c}_{\mu(n)})$

The voxel feature $\mathbf{f}_i \in \mathbb{R}^{D_{\text{in}} + D_{\text{enc}}}$ is formed by concatenating point features with positional encodings and aggregating over intra-voxel points using a permutation-invariant operator $\Omega$ (e.g., average pooling): $\mathbf{f}_i = \Omega_{n \in \mathcal{M}(i)}(\mathbf{i}_n \oplus \mathbf{e}_n)$ where $\oplus$ denotes vector concatenation.

During devoxelization, given updated voxel features $\mathbf{f}'_i \in \mathbb{R}^{D_{\text{out}}}$ , the continuous output point features $\mathbf{o}_n \in \mathbb{R}^{D_{\text{out}}}$ are reconstructed via a multilayer perceptron $\text{MLP}: \mathbb{R}^{D_{\text{out}} + D_{\text{enc}}} \to \mathbb{R}^{D_{\text{out}}}$ : $\mathbf{o}_n = \text{MLP}(\mathbf{f}'_{\mu(n)} \oplus \mathbf{e}_n)$
Knowl 3 — Coordinate Decomposition for Space Complexity Reduction in Continuous Positional Encoding
theoretical result
In local self-attention over continuous voxel centroids $\mathbf{c}_i, \mathbf{c}_j \in \mathbb{R}^3$ , directly computing continuous relative positional encodings $\delta(\mathbf{c}_i, \mathbf{c}_j) = \text{MLP}(\mathbf{c}_i - \mathbf{c}_j)$ requires $\mathcal{O}(IKD)$ space complexity, where $I$ is the number of voxels, $K$ is the number of local neighbors per voxel, and $D$ is the encoding dimension. This overhead arises because continuous centroids produce up to $\mathcal{O}(IK)$ distinct pairwise relative displacement vectors $(\mathbf{c}_i - \mathbf{c}_j)$ .

Fast Point Transformer decomposes the relative centroid displacement using discrete voxel grid coordinates $\mathbf{v}_i, \mathbf{v}_j \in \mathbb{Z}^3$ : $\mathbf{c}_i - \mathbf{c}_j = (\mathbf{c}_i - \mathbf{v}_i) - (\mathbf{c}_j - \mathbf{v}_j) + (\mathbf{v}_i - \mathbf{v}_j)$

This decomposition enables splitting the positional encoding into:
1. A continuous intra-voxel offset $\delta_{\text{abs}}(\mathbf{c}_i - \mathbf{v}_i) \in \mathbb{R}^D$ stored per voxel, requiring $\mathcal{O}(ID)$ space.
2. A discretized inter-voxel relative displacement $\delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j) \in \mathbb{R}^D$ , requiring $\mathcal{O}(KD)$ space because there are at most $K$ distinct discrete relative neighbor offsets in $\mathbb{Z}^3$ .
Because $\delta_{\text{abs}}(\mathbf{c}_j - \mathbf{v}_j)$ is reused across queries, the total space complexity for continuous relative positional encoding is reduced from $\mathcal{O}(IKD)$ to $\mathcal{O}(ID + KD)$ .
Knowl 4 — Lightweight Self-Attention (LSA) Layer Formulation
equation
The Lightweight Self-Attention (LSA) layer in Fast Point Transformer updates the feature representation of voxel centroid $i$ over its local neighbor set $\mathcal{N}(i)$ using cosine similarity between centroid-aware query features and discretized relative positional encodings: $\mathbf{f}'_i = \sum_{j \in \mathcal{N}(i)} \frac{\phi(\mathbf{g}_i) \cdot \delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j)}{\|\phi(\mathbf{g}_i)\|\|\delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j)\|} \psi(\mathbf{g}_j)$ where:
- $\mathbf{g}_i = \mathbf{f}_i + \delta_{\text{abs}}(\mathbf{c}_i - \mathbf{v}_i)$ is the centroid-aware voxel feature, combining the voxel feature $\mathbf{f}_i$ with the continuous intra-voxel positional encoding $\delta_{\text{abs}}(\mathbf{c}_i - \mathbf{v}_i)$ .
- $\mathbf{v}_i, \mathbf{v}_j \in \mathbb{Z}^3$ are discrete voxel coordinates.
- $\delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j) \in \mathbb{R}^D$ is the discretized relative positional encoding.
- $\phi(\cdot)$ and $\psi(\cdot)$ denote linear projection functions for queries and values, respectively.
- $\mathcal{N}(i)$ denotes the set of local voxel neighbor indices queried via voxel hashing.
Cosine similarity is utilized instead of softmax normalization $\text{softmax}(\phi(\mathbf{g}_i)^\top \delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j))$ because 3D point cloud voxel grids have variable neighborhood sizes $|\mathcal{N}(i)|$ . In sparse boundary regions where $|\mathcal{N}(i)| = 1$ , softmax normalizes the weight to 1.0 (reducing the attention mechanism to a static linear layer), whereas cosine similarity provides dynamic, magnitude-normalized weighting across varying voxel densities.
Knowl 5 — Consistency Score (CScore) Metric for Rigid Transformation Invariance
definition
The Consistency Score (CScore) measures the semantic prediction coherence of a 3D point cloud model under rigid geometric transformations (rotations and translations). Given a set of point clouds $\mathcal{S} = \{\mathcal{P}^{\text{in}}\}$ , a 3D semantic segmentation model $f: \mathcal{P}^{\text{in}} \to \mathcal{C}$ mapping input points $(\mathbf{p}_n, \mathbf{i}_n)$ to semantic classes $\mathcal{C}$ , and a set of rigid transformations $\mathcal{T} = \{\mathbf{T}_m\}$ , the consistency score $\text{CScore}(f; \mathcal{S}, \mathcal{T})$ is defined as: $\text{CScore}(f; \mathcal{S}, \mathcal{T}) = \frac{1}{|\mathcal{S}|} \sum_{\mathcal{P}^{\text{in}} \in \mathcal{S}} \frac{1}{|\mathcal{P}^{\text{in}}| |\mathcal{T}|} \sum_{n=1}^{|\mathcal{P}^{\text{in}}|} \sum_{m=1}^{|\mathcal{T}|} \mathbb{I}\Big(f(\mathbf{p}_n, \mathbf{i}_n), f(\mathbf{T}_m \mathbf{p}_n, \mathbf{i}_n)\Big)$ where $\mathbb{I}(\cdot, \cdot)$ is the indicator function returning 1 if the predicted class of the unperturbed point equals that of the transformed point, and 0 otherwise.

In standard evaluation benchmarks on ScanNet validation with voxel size $L$ , $\mathcal{T}$ comprises 41 rigid transformations:
- 26 3D translations: $\{0, L/3, 2L/3\}^3 \setminus \{[0, 0, 0]\}$ .
- 15 rotations around the gravity axis: $\{0.125\pi, 0.25\pi, \dots, 1.875\pi\}$ .

Knowl 6 — Inference Latency and Semantic Segmentation Performance on S3DIS Area 5

data/table

On the S3DIS dataset Area 5 test split, Fast Point Transformer achieves competitive accuracy to point-based transformer architectures while operating at single-shot voxel speeds, running 129 times faster than Point Transformer.

Method	Neighbor Prep.	Neighbor Infer.	Inference Style	Latency (s)	mAcc (%)	mIoU (%)
PointNet	None	None	Crop-and-stitch	18.16	49.0	41.1
SPGraph	None	None	Crop-and-stitch	18.28	66.5	58.0
PointWeb	$\mathcal{O}(1)$	$\mathcal{O}(MNK)$	Crop-and-stitch	11.62	66.6	60.3
MinkowskiNet32 (5cm)	$\mathcal{O}(N)$	$\mathcal{O}(M)$	Single-shot	0.08	71.7	65.4
KPConv deform	$\mathcal{O}(N \log N)$	$\mathcal{O}(KM \log N)$	Multi-shot	105.15	72.8	67.1
PAConv	$\mathcal{O}(1)$	$\mathcal{O}(MN \log K)$	Crop-and-stitch	28.13	73.0	66.6
PointTransformer	$\mathcal{O}(1)$	$\mathcal{O}(MN \log K)$	Multi-shot	18.07	76.5	70.4
Voxel size: 4cm
MinkowskiNet42	$\mathcal{O}(N)$	$\mathcal{O}(M)$	Single-shot	0.08	$74.4 \pm 0.8$	$67.1 \pm 0.1$
+ rotation average	$\mathcal{O}(N)$	$\mathcal{O}(M)$	Multi-shot	0.66	$75.0 \pm 0.7$	$68.4 \pm 0.1$
FastPointTransformer (ours)	$\mathcal{O}(N)$	$\mathcal{O}(M)$	Single-shot	0.14	$76.5 \pm 0.6$	$68.5 \pm 0.2$
+ rotation average	$\mathcal{O}(N)$	$\mathcal{O}(M)$	Multi-shot	1.13	$77.3 \pm 0.7$	$70.1 \pm 0.3$

Here $N$ is the number of dataset points, $M$ is the number of query points (or voxel centroids), and $K$ is the neighborhood size ( $M, N \gg K$ ). Latency is measured per scene on an Intel Core i7-5930K CPU and an NVIDIA GeForce RTX 3090 GPU.

Knowl 7 — Prediction Consistency and Accuracy Across Voxel Resolutions on ScanNet

data/table

Fast Point Transformer demonstrates significantly higher consistency scores (CScore) and semantic segmentation accuracy (mIoU) across different voxel resolutions on the ScanNet validation dataset compared to the baseline voxel network MinkowskiNet42, demonstrating robust suppression of quantization artifacts.

Method	CScore (%) - R	CScore (%) - t	CScore (%) - R t	mIoU (%)
Voxel size: 10cm
MinkowskiNet42	$92.2 \pm 0.1$	$92.0 \pm 0.1$	$92.0 \pm 0.1$	$60.5 \pm 0.2$
FastPointTransformer	$94.7 \pm 0.3$	$94.6 \pm 0.1$	$94.6 \pm 0.1$	$65.9 \pm 0.6$
Voxel size: 5cm
MinkowskiNet42	$94.2 \pm 0.1$	$95.1 \pm 0.1$	$94.8 \pm 0.1$	$66.7 \pm 0.2$
FastPointTransformer	$95.9 \pm 0.4$	$96.4 \pm 0.1$	$96.2 \pm 0.2$	$70.0 \pm 0.1$
Voxel size: 2cm
MinkowskiNet42	$95.9 \pm 0.6$	$96.9 \pm 0.3$	$96.6 \pm 0.1$	$71.9 \pm 0.2$
FastPointTransformer	$96.9 \pm 0.3$	$97.4 \pm 0.4$	$97.2 \pm 0.1$	$72.1 \pm 0.3$

Transformations evaluated include 15 rotations around the gravity axis (R), 26 grid translations (t), and both combined (R & t). At larger voxel sizes (10cm and 5cm) where quantization artifacts are most severe, Fast Point Transformer outperforms MinkowskiNet42 by $+5.4\%$ and $+3.3\%$ mIoU, respectively.

Knowl 8 — Model Parameter Scaling and Compression Resilience on ScanNet

data/table

When network capacity is reduced by decreasing the number of building blocks, Fast Point Transformer retains its segmentation performance on ScanNet validation, whereas MinkowskiNet degrades significantly.

Method	# Param. (M)	Rel. Param. (%)	mIoU (%)	$\Delta$ mIoU (%)
Voxel size: 10cm
MinkowskiNet42	37.9	$\pm 0.0$	$60.5 \pm 0.2$	$\pm 0.0$
MinkowskiNet (small)	21.7	$-42.7$	$59.9 \pm 0.6$	$-0.6$
MinkowskiNet (smaller)	11.6	$-69.4$	$58.2 \pm 0.9$	$-2.3$
FastPointTransformer	37.9	$\pm 0.0$	$65.9 \pm 0.6$	$\pm 0.0$
FastPointTransformer (small)	20.2	$-46.7$	$66.0 \pm 0.3$	$+0.1$
FastPointTransformer (smaller)	10.8	$-71.5$	$65.7 \pm 0.1$	$-0.2$
Voxel size: 5cm
MinkowskiNet42	37.9	$\pm 0.0$	$66.7 \pm 0.3$	$\pm 0.0$
MinkowskiNet (small)	21.7	$-42.7$	$66.0 \pm 0.1$	$-0.7$
MinkowskiNet (smaller)	11.6	$-69.4$	$64.2 \pm 0.4$	$-2.5$
FastPointTransformer	37.9	$\pm 0.0$	$70.0 \pm 0.1$	$\pm 0.0$
FastPointTransformer (small)	20.2	$-46.7$	$70.3 \pm 0.2$	$+0.3$
FastPointTransformer (smaller)	10.8	$-71.5$	$69.7 \pm 0.2$	$-0.3$

Even with a $71.5\%$ reduction in parameters (10.8M parameters), Fast Point Transformer maintains $65.7\%$ mIoU at 10cm resolution, outperforming the most lightweight MinkowskiNet at 5cm resolution (11.6M parameters, $64.2\%$ mIoU).

Knowl 9 — 3D Object Detection Performance with VoteNet on ScanNet

data/table

Fast Point Transformer serves as an effective feature backbone for 3D object detection within the VoteNet architecture on the ScanNet validation dataset, outperforming both point-based and voxel-based backbones.

Backbone	[email protected] (%)	[email protected] (%)
PointNet++	54.2	30.1
RS-CNN	51.6	29.5
KPConv	48.9	29.2
MinkowskiNet	53.8	30.2
MinkowskiNet (reproduced)	$55.3 \pm 0.2$	$33.0 \pm 0.5$
FastPointTransformer	$59.1 \pm 0.1$	$35.6 \pm 0.4$

Fast Point Transformer improves detection accuracy by $+3.8\%$ [email protected] and $+2.6\%$ [email protected] over the reproduced MinkowskiNet backbone without any changes to the downstream Hough voting or object bounding box proposal modules.

Knowl 10 — Ablation Analysis of Positional Encoding, Attention Formulation, and Local Window Size
empirical result
Ablation studies on the ScanNet validation dataset at 10cm voxel resolution evaluate key design choices in Fast Point Transformer:
1. Positional Encodings: Starting from a base network without continuous positional encodings (59.1% mIoU, 27.3M parameters), adding centroid-aware voxelization encoding $\delta_{\text{enc}}$ increases performance to 61.3% mIoU. Adding centroid-aware devoxelization increases performance to 62.7% mIoU, and incorporating the continuous intra-voxel feature offset $\delta_{\text{abs}}$ achieves the full performance of 65.3% mIoU (37.9M parameters). In contrast, adding $\delta_{\text{abs}}$ to MinkowskiNet42 fails to improve accuracy (65.1% to 65.0% mIoU), indicating that $\delta_{\text{abs}}$ specifically benefits dynamic self-attention.
2. Attention Types: Cosine similarity on query and relative position $\text{cosine}(\phi(\mathbf{g}_i), \delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j))$ achieves 65.3% mIoU, outperforming softmax attention $\text{softmax}(\phi(\mathbf{g}_i), \delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j))$ at 61.0% mIoU and cosine attention including query-key feature similarity $\text{cosine}(\phi(\mathbf{g}_i), \xi(\mathbf{g}_j) + \delta_{\text{rel}}(\mathbf{v}_i - \mathbf{v}_j))$ at 62.1% mIoU.
3. Local Window Size: A local window size of $k=3$ gives 65.3% mIoU with 0.106s latency. Increasing the local window size degrades performance ( $k=5$ : 62.4% mIoU, 0.127s latency; $k=7$ : 61.9% mIoU, 0.168s latency) due to the sparsity of 3D voxel data when utilizing learnable positional tokens.

Coverage note — No substantial contributed material was omitted.
