BAM: Bottleneck Attention Module

Jongchan ParkSanghyun WooJoon-Young LeeIn-So Kweon

article2018BMVC1,340 citationsSilver Prize, Best Paper Award

Introduces a lightweight dual-pathway attention module placed at convolutional bottlenecks to improve image classification and object detection performance across diverse architectures with minimal computational overhead.

Listen

Modern artificial intelligence systems rely heavily on deep neural networks for visual recognition tasks, but traditional methods of improving accuracy—such as stacking more layers or widening networks—dramatically increase computational cost and memory requirements. As visual applications expand to resource-constrained environments like mobile and embedded systems, organizations face the operational challenge of improving model accuracy without incurring high latency and hardware expenses.

The article introduces and evaluates the Bottleneck Attention Module, a lightweight component designed to improve the accuracy of convolutional neural networks. The objective is to demonstrate that placing this module at key transition points in a network enhances performance across multiple visual recognition tasks with minimal computational overhead.

The researchers evaluated the module using standard benchmark datasets, including CIFAR-100 and ImageNet-1K for image classification, as well as VOC 2007 and MS COCO for object detection. The method computes attention through two separate, complementary streams: a channel branch that determines which features are important, and a spatial branch using dilated convolutions to determine where in an image to focus. These two streams are combined through element-wise addition and integrated specifically at the bottleneck locations where networks downsample image data.

The evaluation produced several key findings. First, integrating the module consistently reduced classification error across various baseline architectures, cutting error rates on CIFAR-100 by approximately 0.5 to 1.5 percentage points while adding almost no parameters; for instance, a ResNet-50 model with the module matched the accuracy of a ResNet-101 model while using roughly half the parameters. Second, the module improved large-scale image classification on ImageNet-1K across deep, wide, and compact architectures, reducing top-1 error by up to 1.77 percentage points in efficient mobile models. Third, the module improved object detection accuracy on both MS COCO and VOC 2007 benchmarks. Finally, comparative tests demonstrated that combining spatial and channel attention at bottleneck locations delivered better accuracy and parameter efficiency than existing alternatives such as Squeeze-and-Excitation modules or placing attention inside every convolutional block.

These findings indicate that organizations deploying computer vision can achieve higher accuracy without the financial and operational burdens of larger server infrastructure or excessive latency on edge devices. By refining features at critical network bottlenecks, models learn hierarchical representations that filter background noise early and focus on target objects in deeper layers, mimicking efficient human visual perception.

Engineering and deployment teams should consider integrating the module into existing vision pipelines, particularly where resource efficiency is critical, by using the demonstrated reduction ratio and dilation parameters. Future work should explore combining this attention mechanism with specialized network compression techniques to further optimize edge device performance.

Confidence in these findings is high given the broad evaluation across multiple architectures and standardized benchmarks. However, stakeholders should note that the reported gains vary by specific backbone model and that real-world deployment on proprietary, domain-specific visual data should be validated before full system adoption.

Adobe Korea Advanced Institute of Science and Technology Lunit Inc.classification convolutional neural networks detection performance Bottleneck Attention Module spatial attention branch channel attention

arXiv: 1807.06514

Paper: Squeeze-and-Excitation Networks, Jie Hu et al. (2018). This paper establishes the foundational Squeeze-and-Excitation channel attention mechanism that BAM builds upon and extends with a parallel spatial attention branch.
Paper: Residual Attention Network for Image Classification, Fei Wang et al. (2017). This work pioneered the integration of modular residual attention blocks inside deep feed-forward convolutional networks, motivating BAM's bottleneck placement and residual formulation.
Paper: SCA-CNN: Spatial and Channel-Wise Attention in Convolutional Networks for Image Captioning, Long Chen et al. (2016). This paper introduces the concept of jointly combining spatial and channel-wise attention in CNN feature maps to capture both semantic content and localization.
Paper: Paying More Attention to Attention: Improving the Performance of Convolutional Neural Networks via Attention Transfer, Sergey Zagoruyko et al. (2017). This study formulates spatial attention map generation from intermediate CNN activation tensors, informing how spatial statistics are extracted and utilized.
Paper: MobileNetV2: Inverted Residuals and Linear Bottlenecks, Mark Sandler et al. (2018). This work details the bottleneck and downsampling design patterns in modern deep CNN architectures where BAM is explicitly designed to be placed.

Paper: CBAM: Convolutional Block Attention Module, Sanghyun Woo et al. (2018). Developed by the same authors, CBAM refines BAM by exploring a sequential channel-spatial attention structure applied at every convolutional block rather than solely at bottlenecks.
Paper: ECA-Net: Efficient Channel Attention for Deep Convolutional Neural Networks, Qilong Wang et al. (2019). This work advances lightweight CNN attention by directly comparing against BAM and CBAM while replacing MLP-based channel attention with 1D convolutions.
Paper: Coordinate Attention for Efficient Mobile Network Design, Qibin Hou et al. (2021). Coordinate Attention extends spatial-channel feature recalibration to mobile architectures by embedding directional coordinate awareness into channel attention.
Paper: Attention mechanisms in computer vision: A survey, Meng-Hao Guo et al. (2021). This comprehensive survey categorizes visual attention mechanisms and provides comparative context for dual channel-spatial modules like BAM and CBAM.
Paper: SimAM: A Simple, Parameter-Free Attention Module for Convolutional Neural Networks, Lingxiao Yang et al. (2021). SimAM investigates parameter-free, 3D neuron-level attention as an alternative to the dual-branch channel and spatial designs exemplified by BAM.
Paper: Efficient Multi-Scale Attention Module with Cross-Spatial Learning, Daliang Ouyang et al. (2023). This paper extends multi-branch CNN attention mechanisms by introducing cross-spatial learning across parallel branches without channel reduction.
Paper: GCNet: Non-Local Networks Meet Squeeze-Excitation Networks and Beyond, Yue Cao et al. (2019). GCNet unifies Squeeze-and-Excitation channel modeling with self-attention global context, advancing the dual-attention paradigm across CNN backbones.
Paper: Selective Kernel Networks, Xiang Li et al. (2019). Selective Kernel Networks build on adaptive CNN feature recalibration by applying dynamic channel attention across multi-scale convolutional kernels.

Cover for BAM: Bottleneck Attention Module

Abstract

Recent advances in deep neural networks have been developed via architecture search for stronger representational power. In this work, we focus on the effect of attention in general deep neural networks. We propose a simple and effective attention module, named Bottleneck Attention Module (BAM), that can be integrated with any feed-forward convolutional neural networks. Our module infers an attention map along two separate pathways, channel and spatial. We place our module at each bottleneck of models where the downsampling of feature maps occurs. Our module constructs a hierarchical attention at bottlenecks with a number of parameters and it is trainable in an end-to-end manner jointly with any feed-forward models. We validate our BAM through extensive experiments on CIFAR-100, ImageNet-1K, VOC 2007 and MS COCO benchmarks. Our experiments show consistent improvement in classification and detection performances with various models, demonstrating the wide applicability of BAM. The code and models will be publicly available.

Topics

classification convolutional neural networks detection performance feedforward neural networks

Keywords

Bottleneck Attention Module spatial attention branch channel attention residual attention attention mechanism convolutional networks object detection

1 Introduction
2 Related Work
3 Bottleneck Attention Module
4 Experiments
4.1 Ablation studies on CIFAR-100
4.2 Classification Results on CIFAR-100
4.3 Classification Results on ImageNet-1K
4.4 Effectiveness of BAM with Compact Networks
4.5 MS COCO Object Detection
4.6 VOC 2007 Object Detection
4.7 Comparison with Squeeze-and-Excitation[Hu et al.(2017)Hu, Shen, and Sun]
5 Conclusion
References

Knowls

Knowl 1 — Bottleneck Attention Module (BAM) Architecture and Refinement
model/method
The Bottleneck Attention Module (BAM) is an attention mechanism designed to refine an intermediate 3D feature representation $\mathbf{F} \in \mathbb{R}^{C \times H \times W}$ (where $C$ is the number of channels, $H$ is height, and $W$ is width) within deep convolutional neural networks. BAM decomposes the computation of a 3D attention map $\mathbf{M}(\mathbf{F}) \in \mathbb{R}^{C \times H \times W}$ into two parallel branches: a channel attention branch $\mathbf{M}_c(\mathbf{F}) \in \mathbb{R}^{C}$ that determines what feature attributes to emphasize, and a spatial attention branch $\mathbf{M}_s(\mathbf{F}) \in \mathbb{R}^{H \times W}$ that determines where to focus.

The final 3D attention map is produced by expanding both branch outputs to $\mathbb{R}^{C \times H \times W}$ , summing them element-wise, and passing the result through a sigmoid activation function $\sigma$ :

$\mathbf{M}(\mathbf{F}) = \sigma\left(\mathbf{M}_c(\mathbf{F}) + \mathbf{M}_s(\mathbf{F})\right)$

The refined feature map $\mathbf{F}' \in \mathbb{R}^{C \times H \times W}$ is then computed using a residual learning formulation:

$\mathbf{F}' = \mathbf{F} + \mathbf{F} \otimes \mathbf{M}(\mathbf{F})$

where $\otimes$ denotes element-wise multiplication. The residual connection ensures smooth gradient flow during end-to-end backpropagation.
Knowl 2 — BAM Channel Attention Pathway
model/method
The channel attention branch computes inter-channel dependencies from the input tensor $\mathbf{F} \in \mathbb{R}^{C \times H \times W}$ . Global contextual information for each channel is first aggregated using global average pooling:

$\mathbf{F}_c = \text{AvgPool}(\mathbf{F}) \in \mathbb{R}^{C \times 1 \times 1}$

To model non-linear interactions across channels while constraining parameter overhead, $\mathbf{F}_c$ is passed through a multi-layer perceptron (MLP) with a single hidden layer of reduced dimension $\mathbb{R}^{C/r \times 1 \times 1}$ , where $r$ is the reduction ratio (set by default to $r=16$ ). A Batch Normalization ( $\text{BN}$ ) layer is applied at the output to align the scale of the channel attention with the spatial branch output:

$\mathbf{M}_c(\mathbf{F}) = \text{BN}\left(\mathbf{W}_1\left(\mathbf{W}_0\text{AvgPool}(\mathbf{F}) + \mathbf{b}_0\right) + \mathbf{b}_1\right)$

where $\mathbf{W}_0 \in \mathbb{R}^{C/r \times C}$ , $\mathbf{b}_0 \in \mathbb{R}^{C/r}$ , $\mathbf{W}_1 \in \mathbb{R}^{C \times C/r}$ , and $\mathbf{b}_1 \in \mathbb{R}^{C}$ .
Knowl 3 — BAM Spatial Attention Pathway with Dilated Convolutions
model/method
The spatial attention branch computes a spatial weight map $\mathbf{M}_s(\mathbf{F}) \in \mathbb{R}^{H \times W}$ to emphasize informative regions and suppress background noise. To capture contextual dependencies over wide spatial regions efficiently, the branch employs dilated convolutions arranged in a bottleneck topology:

$\mathbf{M}_s(\mathbf{F}) = \text{BN}\left(f_3^{1\times 1}\left(f_2^{3\times 3}\left(f_1^{3\times 3}\left(f_0^{1\times 1}(\mathbf{F})\right)\right)\right)\right)$

where:
- $f_0^{1\times 1}$ is a $1\times 1$ convolution that projects $\mathbf{F} \in \mathbb{R}^{C \times H \times W}$ down to $\mathbb{R}^{C/r \times H \times W}$ using reduction ratio $r=16$ .
- $f_1^{3\times 3}$ and $f_2^{3\times 3}$ are two successive $3\times 3$ dilated convolutions with dilation rate $d=4$ , operating in the reduced channel dimension $C/r$ to enlarge the effective receptive field without parameter inflation.
- $f_3^{1\times 1}$ is a $1\times 1$ convolution reducing the channel dimension from $C/r$ to $1$ , yielding a tensor in $\mathbb{R}^{1 \times H \times W}$ .
- $\text{BN}$ is a batch normalization layer applied to adjust the output scale prior to combination with the channel branch.
Knowl 4 — Network Bottleneck Placement Strategy for Attention Modules
model/method
BAM is integrated specifically at the bottlenecks of convolutional neural network architectures—the transition interfaces between distinct stages where spatial downsampling occurs (e.g., via pooling or strided operations) and channel dimensions increase. Rather than inserting attention mechanisms inside every convolutional block, placing BAM at stage bottlenecks concentrates feature refinement at critical points of information flow, denoising low-level features at early bottlenecks and focusing on high-level semantics at later bottlenecks while minimizing computational (FLOPs) and parametric overhead.

Knowl 5 — Ablation on BAM Branch Composition and Combination Operations

empirical result

Ablation experiments on the CIFAR-100 dataset using a ResNet-50 backbone (baseline top-1 error: $21.49\%$ ) evaluate the effectiveness of individual attention branches and different combining operators:

Configuration	Channel Branch	Spatial Branch	Combining Op	Top-1 Error (%)
Baseline (ResNet-50)	-	-	-	21.49
Channel-only	✓		-	21.29
Spatial-only		✓	-	21.24
BAM (Element-wise Max)	✓	✓	MAX	20.28
BAM (Element-wise Product)	✓	✓	PROD	20.21
BAM (Element-wise Sum)	✓	✓	SUM	20.00

Combining both channel and spatial branches outperforms using either branch in isolation. Among the combining methods, element-wise summation achieves the lowest error ( $20.00\%$ ) because it allows bidirectional, equal gradient distribution to both branches during backward propagation and retains complementary information from both pathways. Element-wise product produces inferior results because large gradients are assigned to small inputs, impeding convergence, while element-wise maximum routes gradients only to the dominant branch, destabilizing training.

Knowl 6 — Hyperparameter Optimization for BAM Dilation Rate and Reduction Ratio

empirical result

Ablation experiments on CIFAR-100 with ResNet-50 evaluate the sensitivity of BAM to the spatial dilation rate $d$ and channel reduction ratio $r$ :

Hyperparameter	Value	Parameters	Top-1 Error (%)
Baseline (ResNet-50)	-	23.68M	21.49
Dilation rate ( $d$ )	1	24.07M	20.47
	2	24.07M	20.28
	4	24.07M	20.00
	6	24.07M	20.08
Reduction ratio ( $r$ )	4	26.30M	20.46
	8	24.62M	20.56
	16	24.07M	20.00
	32	23.87M	21.24

Standard convolutions ( $d=1$ ) yield the highest error ( $20.47\%$ ), while dilated convolutions expand the receptive field to capture context, with performance saturating at $d=4$ ( $20.00\%$ ). For the reduction ratio, $r=16$ provides the best trade-off between representational capacity and regularization; lower ratios ( $r=4, 8$ ) incur higher parameter counts and suffer from overfitting.

Knowl 7 — Bottleneck Placement vs. Inside-Block Insertion (BAM-C)

empirical result

Comparing the placement of BAM at network bottlenecks against inserting attention inside every convolutional block (designated BAM-C) across standard architectures on CIFAR-100:

Architecture	Params	GFLOPs	Top-1 Error (%)
ResNet-50 Baseline	23.71M	1.22	21.49
ResNet-50 + BAM-C	28.98M	1.37	20.88
ResNet-50 + BAM	24.07M	1.25	20.00
PreResNet-110 Baseline	1.73M	0.245	22.22
PreResNet-110 + BAM-C	2.17M	0.275	21.29
PreResNet-110 + BAM	1.73M	0.246	21.96
WideResNet-28 ( $w=8$ ) Baseline	23.40M	3.36	20.40
WideResNet-28 ( $w=8$ ) + BAM-C	23.78M	3.39	20.06
WideResNet-28 ( $w=8$ ) + BAM	23.42M	3.37	19.06
ResNeXt-29 ( $8\times 64\text{d}$ ) Baseline	34.52M	4.99	18.18
ResNeXt-29 ( $8\times 64\text{d}$ ) + BAM-C	35.60M	5.07	18.15
ResNeXt-29 ( $8\times 64\text{d}$ ) + BAM	34.61M	5.00	16.71

Placing BAM strictly at the bottlenecks achieves superior accuracy-to-overhead trade-offs compared to inserting modules inside every convolutional block, reducing error by larger margins while adding substantially fewer parameters and GFLOPs.

Knowl 8 — ImageNet-1K Classification Performance Across Deep and Compact Architectures

empirical result

Evaluation of BAM on the ImageNet-1K validation set (single-crop $224 \times 224$ evaluation) across standard, wide, multi-branch, and mobile architectures:

Architecture	Params	GFLOPs	Top-1 Error (%)	Top-5 Error (%)
ResNet-18	11.69M	1.81	29.60	10.55
ResNet-18 + BAM	11.71M (+0.02)	1.82 (+0.01)	28.88	10.01
ResNet-50	25.56M	3.86	24.56	7.50
ResNet-50 + BAM	25.92M (+0.36)	3.94 (+0.08)	24.02	7.18
ResNet-101	44.55M	7.57	23.38	6.88
ResNet-101 + BAM	44.91M (+0.36)	7.65 (+0.08)	22.44	6.29
WideResNet-18 ( $w=1.5$ )	25.88M	3.87	26.85	8.88
WideResNet-18 ( $w=1.5$ ) + BAM	25.93M (+0.05)	3.88 (+0.01)	26.67	8.69
WideResNet-18 ( $w=2.0$ )	45.62M	6.70	25.63	8.20
WideResNet-18 ( $w=2.0$ ) + BAM	45.71M (+0.09)	6.72 (+0.02)	25.00	7.81
ResNeXt-50 ( $32\times 4\text{d}$ )	25.03M	3.77	22.85	6.48
ResNeXt-50 ( $32\times 4\text{d}$ ) + BAM	25.39M (+0.36)	3.85 (+0.08)	22.56	6.40
MobileNet	4.23M	0.569	31.39	11.51
MobileNet + BAM	4.32M (+0.09)	0.589 (+0.02)	30.58	10.90
MobileNet ( $\alpha=0.7$ )	2.30M	0.283	34.86	13.69
MobileNet ( $\alpha=0.7$ ) + BAM	2.34M (+0.04)	0.292 (+0.009)	33.09	12.69
MobileNet ( $\rho=192/224$ )	4.23M	0.439	32.89	12.33
MobileNet ( $\rho=192/224$ ) + BAM	4.32M (+0.09)	0.456 (+0.017)	31.56	11.60
SqueezeNet v1.1	1.24M	0.290	43.09	20.48
SqueezeNet v1.1 + BAM	1.26M (+0.02)	0.304 (+0.014)	41.83	19.58

Inserting only three BAM modules across the entire network reduces error rates consistently across all network scales with negligible overhead.

Knowl 9 — BAM vs. Squeeze-and-Excitation (SE) on CIFAR-100

empirical result

Comparative performance of BAM versus Squeeze-and-Excitation (SE) modules on the CIFAR-100 benchmark:

Architecture	Params	GFLOPs	Top-1 Error (%)
ResNet-50 Baseline	23.71M	1.22	21.49
ResNet-50 + SE	26.24M	1.23	20.72
ResNet-50 + BAM	24.07M	1.25	20.00
PreResNet-110 Baseline	1.73M	0.245	22.22
PreResNet-110 + SE	1.93M	0.245	21.85
PreResNet-110 + BAM	1.73M	0.246	21.96
WideResNet-28 ( $w=8$ ) Baseline	23.40M	3.36	20.40
WideResNet-28 ( $w=8$ ) + SE	23.58M	3.36	19.85
WideResNet-28 ( $w=8$ ) + BAM	23.42M	3.37	19.06
ResNeXt-29 ( $16\times 64\text{d}$ ) Baseline	68.25M	9.88	17.25
ResNeXt-29 ( $16\times 64\text{d}$ ) + SE	68.81M	9.88	16.52
ResNeXt-29 ( $16\times 64\text{d}$ ) + BAM	68.34M	9.90	16.39

BAM achieves lower top-1 classification error than SE on ResNet-50 ( $20.00\%$ vs. $20.72\%$ ), WideResNet-28 ( $19.06\%$ vs. $19.85\%$ ), and ResNeXt-29 ( $16.39\%$ vs. $16.52\%$ ) while using fewer parameters because BAM is placed only at stage bottlenecks rather than within every convolutional block.

Knowl 10 — Object Detection Performance on MS COCO and PASCAL VOC 2007

empirical result

Performance of BAM integrated into object detection frameworks on MS COCO and PASCAL VOC 2007:

(a) MS COCO Detection (Faster-RCNN with ResNet-101)
Architecture		[email protected]	[email protected]	mAP@[0.5, 0.95]
ResNet-101 Baseline		48.4	30.7	29.1
ResNet-101 + BAM		50.2	32.5	30.4
(b) PASCAL VOC 2007 Detection
Backbone	Detector	Params (M)	[email protected] (%)
VGG-16	SSD	26.5	77.8
VGG-16	StairNet	32.0	78.9
VGG-16	StairNet + BAM	32.1	79.3
MobileNet	SSD	5.81	68.1
MobileNet	StairNet	5.98	70.1
MobileNet	StairNet + BAM	6.00	70.6

On MS COCO, adding BAM to the ResNet-101 backbone of Faster-RCNN improves [email protected] by $+1.8\%$ and overall mAP@[0.5, 0.95] by $+1.3\%$ . On VOC 2007, inserting BAM right before classifiers in StairNet increases [email protected] by $+0.4\%$ on VGG-16 and $+0.5\%$ on MobileNet with minimal parameter increase ( $+0.1\text{M}$ and $+0.02\text{M}$ params).

Coverage note — Qualitative visual attention heatmaps across network stages were omitted as they serve illustrative analysis rather than standalone quantitative contributions.

References

1.Pytorch. http://pytorch.org/. Accessed: 2018-04-20.
2.Jimmy Ba, Volodymyr Mnih, and Koray Kavukcuoglu. Multiple object recognition with visual attention. 2014.
3.Dzmitry Bahdanau, Kyunghyun Cho, and Yoshua Bengio. Neural machine translation by jointly learning to align and translate. 2014.
4.Sean Bell, C Lawrence Zitnick, Kavita Bala, and Ross Girshick. Inside-outside net: Detecting objects in context with skip pooling and recurrent neural networks. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2016.
5.Liang-Chieh Chen, George Papandreou, Iasonas Kokkinos, Kevin Murphy, and Alan L Yuille. Deeplab: Semantic image segmentation with deep convolutional nets, atrous convolution, and fully connected crfs. arXiv preprint arXiv:1606.00915, 2016.
6.Long Chen, Hanwang Zhang, Jun Xiao, Liqiang Nie, Jian Shao, and Tat-Seng Chua. Sca-cnn: Spatial and channel-wise attention in convolutional networks for image captioning. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2017.
7.François Chollet. Xception: Deep learning with depthwise separable convolutions. arXiv preprint arXiv:1610.02357, 2016.
8.Maurizio Corbetta and Gordon L Shulman. Control of goal-directed and stimulus-driven attention in the brain. In Nature reviews neuroscience 3.3, 2002.
9.Jifeng Dai, Haozhi Qi, Yuwen Xiong, Yi Li, Guodong Zhang, Han Hu, and Yichen Wei. Deformable convolutional networks. CoRR, abs/1703.06211, 1(2):3, 2017.
10.Jia Deng, Wei Dong, Richard Socher, Li-Jia Li, Kai Li, and Li Fei-Fei. Imagenet: A large-scale hierarchical image database. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2009.
11.Ian Goodfellow, Jean Pouget-Abadie, Mehdi Mirza, Bing Xu, David Warde-Farley, Sherjil Ozair, Aaron Courville, and Yoshua Bengio. Generative adversarial nets. In Advances in neural information processing systems, pages 2672–2680, 2014.
12.Karol Gregor, Ivo Danihelka, Alex Graves, Danilo Jimenez Rezende, and Daan Wierstra. Draw: A recurrent neural network for image generation. 2015.
13.Dongyoon Han, Jiwhan Kim, and Junmo Kim. Deep pyramidal residual networks. In Computer Vision and Pattern Recognition (CVPR), 2017 IEEE Conference on, pages 6307–6315. IEEE, 2017.
14.Bharath Hariharan, Pablo Arbeláez, Ross Girshick, and Jitendra Malik. Hypercolumns for object segmentation and fine-grained localization. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2015.
15.Kaiming He, Xiangyu Zhang, Shaoqing Ren, and Jian Sun. Deep residual learning for image recognition. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2016.
16.Kaiming He, Xiangyu Zhang, Shaoqing Ren, and Jian Sun. Identity mappings in deep residual networks. In Proc. of European Conf. on Computer Vision (ECCV), 2016.
17.Joy Hirsch and Christine A Curcio. The spatial resolution capacity of human foveal retina. Vision research, 29(9):1095–1101, 1989.
18.Andrew G Howard, Menglong Zhu, Bo Chen, Dmitry Kalenichenko, Weijun Wang, Tobias Weyand, Marco Andreetto, and Hartwig Adam. Mobilenets: Efficient convolutional neural networks for mobile vision applications. arXiv preprint arXiv:1704.04861, 2017.
19.Jie Hu, Li Shen, and Gang Sun. Squeeze-and-excitation networks. arXiv preprint arXiv:1709.01507, 2017.
20.Gao Huang, Zhuang Liu, Kilian Q Weinberger, and Laurens van der Maaten. Densely connected convolutional networks. arXiv preprint arXiv:1608.06993, 2016.
21.Gao Huang, Yu Sun, Zhuang Liu, Daniel Sedra, and Kilian Q Weinberger. Deep networks with stochastic depth. In Proc. of European Conf. on Computer Vision (ECCV), 2016.
22.Forrest N Iandola, Song Han, Matthew W Moskewicz, Khalid Ashraf, William J Dally, and Kurt Keutzer. Squeezenet: Alexnet-level accuracy with 50x fewer parameters and <0.5mb model size. arXiv preprint arXiv:1602.07360, 2016.
23.Sergey Ioffe and Christian Szegedy. Batch normalization: Accelerating deep network training by reducing internal covariate shift. 2015.
24.Laurent Itti, Christof Koch, and Ernst Niebur. A model of saliency-based visual attention for rapid scene analysis. In IEEE Trans. Pattern Anal. Mach. Intell. (TPAMI), 1998.
25.Max Jaderberg, Karen Simonyan, Andrew Zisserman, et al. Spatial transformer networks. In Proc. of Neural Information Processing Systems (NIPS), 2015.
26.Max Jaderberg, Karen Simonyan, Andrew Zisserman, et al. Spatial transformer networks. In Advances in neural information processing systems, pages 2017–2025, 2015.
27.Xu Jia, Bert De Brabandere, Tinne Tuytelaars, and Luc V Gool. Dynamic filter networks. In Advances in Neural Information Processing Systems, pages 667–675, 2016.
28.Diederik P Kingma and Jimmy Ba. Adam: A method for stochastic optimization. arXiv preprint arXiv:1412.6980, 2014.
29.Alex Krizhevsky and Geoffrey Hinton. Learning multiple layers of features from tiny images.
30.Alex Krizhevsky, Ilya Sutskever, and Geoffrey E Hinton. Imagenet classification with deep convolutional neural networks. In Proc. of Neural Information Processing Systems (NIPS), 2012.
31.Hugo Larochelle and Geoffrey E Hinton. Learning to combine foveal glimpses with a third-order boltzmann machine. In Proc. of Neural Information Processing Systems (NIPS), 2010.
32.Tsung-Yi Lin, Michael Maire, Serge Belongie, James Hays, Pietro Perona, Deva Ramanan, Piotr Dollár, and C Lawrence Zitnick. Microsoft coco: Common objects in context. In Proc. of European Conf. on Computer Vision (ECCV), 2014.
33.Wei Liu, Dragomir Anguelov, Dumitru Erhan, Christian Szegedy, Scott Reed, Cheng-Yang Fu, and Alexander C Berg. Ssd: Single shot multibox detector. In Proc. of European Conf. on Computer Vision (ECCV), 2016.
34.Jonathan Long, Evan Shelhamer, and Trevor Darrell. Fully convolutional networks for semantic segmentation. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2015.
35.Volodymyr Mnih, Nicolas Heess, Alex Graves, et al. Recurrent models of visual attention." advances in neural information processing systems. In Proc. of Neural Information Processing Systems (NIPS), 2014.
36.Hyeonseob Nam, Jung-Woo Ha, and Jeonghee Kim. Dual attention networks for multimodal reasoning and matching. 2017 IEEE Conference on Computer Vision and Pattern Recognition (CVPR), pages 2156–2164, 2017.
37.Shaoqing Ren, Kaiming He, Ross Girshick, and Jian Sun. Faster r-cnn: Towards real-time object detection with region proposal networks. In Proc. of Neural Information Processing Systems (NIPS), 2015.
38.Ronald A Rensink. The dynamic representation of scenes. In Visual cognition 7.1-3, 2000.
39.Woo Sanghyun, Hwang Soonmin, and Kweon In So. Stairnet: Top-down semantic aggregation for accurate one shot detection. In Proc. of Winter Conf. on Applications of Computer Vision (WACV), 2018.
40.Karen Simonyan and Andrew Zisserman. Very deep convolutional networks for large-scale image recognition. arXiv preprint arXiv:1409.1556, 2014.
41.Christian Szegedy, Wei Liu, Yangqing Jia, Pierre Sermanet, Scott Reed, Dragomir Anguelov, Dumitru Erhan, Vincent Vanhoucke, and Andrew Rabinovich. Going deeper with convolutions. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2015.
42.Fei Wang, Mengqing Jiang, Chen Qian, Shuo Yang, Cheng Li, Honggang Zhang, Xiaogang Wang, and Xiaoou Tang. Residual attention network for image classification. arXiv preprint arXiv:1704.06904, 2017.
43.Saining Xie, Ross Girshick, Piotr Dollár, Zhuowen Tu, and Kaiming He. Aggregated residual transformations for deep neural networks. arXiv preprint arXiv:1611.05431, 2016.
44.Kelvin Xu, Jimmy Ba, Ryan Kiros, Kyunghyun Cho, Aaron Courville, Ruslan Salakhudinov, Rich Zemel, and Yoshua Bengio. Show, attend and tell: Neural image caption generation with visual attention. 2015.
45.Zichao Yang, Xiaodong He, Jianfeng Gao, Li Deng, and Alex Smola. Stacked attention networks for image question answering. In Proc. of Computer Vision and Pattern Recognition (CVPR), 2016.
46.Fisher Yu and Vladlen Koltun. Multi-scale context aggregation by dilated convolutions. 2015.
47.Sergey Zagoruyko and Nikos Komodakis. Wide residual networks. arXiv preprint arXiv:1605.07146, 2016.
48.Matthew D Zeiler. Adadelta: an adaptive learning rate method. arXiv preprint arXiv:1212.5701, 2012.
49.Yousong Zhu, Chaoyang Zhao, Jinqiao Wang, Xu Zhao, Yi Wu, and Hanqing Lu. Couplenet: Coupling global structure with local parts for object detection. In Proc. of IntâA˘Zl Conf. on Computer Vision (ICCV) ´ , 2017.

Citation

MLA

Park, J., et al. “BAM: Bottleneck Attention Module”. arXiv, 2018, http://arxiv.org/abs/1807.06514v2.

APA

Park, J., Woo, S., Lee, J.-Y., & Kweon, I. S. (2018). BAM: Bottleneck Attention Module. arXiv. http://arxiv.org/abs/1807.06514v2

Chicago

Park, J., S. Woo, J.-Y. Lee, and I. S. Kweon. 2018. “BAM: Bottleneck Attention Module”. arXiv. http://arxiv.org/abs/1807.06514v2.

Harvard

Park, J. et al. (2018) “BAM: Bottleneck Attention Module”, arXiv [Preprint]. Available at: http://arxiv.org/abs/1807.06514v2.

Vancouver

1. Park J, Woo S, Lee J-Y, Kweon IS (2018) BAM: Bottleneck Attention Module. arXiv

BibTeX

@article{park2018bam,
  title = {BAM: Bottleneck Attention Module},
  author = {Park, Jongchan and Woo, Sanghyun and Lee, Joon-Young and Kweon, In So},
  year = {2018},
  journal = {arXiv},
  url = {http://arxiv.org/abs/1807.06514v2},
  eprint = {1807.06514}
}

Metadata:arXiv

Access the Paper

This paper is available from its original source. Click below to access the PDF.

Open PDF

License: Authors

BAM: Bottleneck Attention Module

Abstract

Topics

Keywords

Table of Contents

Knowls

Knowl 1 — Bottleneck Attention Module (BAM) Architecture and Refinement

Knowl 2 — BAM Channel Attention Pathway

Knowl 3 — BAM Spatial Attention Pathway with Dilated Convolutions

Knowl 4 — Network Bottleneck Placement Strategy for Attention Modules

Knowl 5 — Ablation on BAM Branch Composition and Combination Operations

Knowl 6 — Hyperparameter Optimization for BAM Dilation Rate and Reduction Ratio

Knowl 7 — Bottleneck Placement vs. Inside-Block Insertion (BAM-C)

Knowl 8 — ImageNet-1K Classification Performance Across Deep and Compact Architectures

Knowl 9 — BAM vs. Squeeze-and-Excitation (SE) on CIFAR-100

Knowl 10 — Object Detection Performance on MS COCO and PASCAL VOC 2007

References

Citation

BibTeX

Access the Paper
