DETRs with Hybrid Matching

Ding JiaYuhui YuanHaodi HeXiaopei WuHaojun YuWeihong LinLei SunChao ZhangHan Hu

article2023CVPR339 citations

Proposes a hybrid matching strategy for DETR architectures that trains an auxiliary one-to-many matching branch alongside the standard one-to-one branch, accelerating training and boosting detection accuracy across diverse vision tasks without adding inference overhead.

Listen

Modern computer vision models increasingly rely on transformer-based architectures that directly predict target objects in an end-to-end manner. To eliminate the need for hand-crafted post-processing steps like non-maximum suppression (a technique that removes duplicate detections), these models strictly assign only one internal query to each real-world target during training. However, this one-to-one matching strategy leaves the vast majority of queries without positive target supervision, which severely restricts training efficiency, slows convergence, and limits final recognition accuracy.

The article introduces and evaluates a hybrid matching framework, designated as H-DETR, designed to accelerate and improve the training of detection transformers. The main objective is to demonstrate that introducing auxiliary training signals allows transformer models to learn better spatial features while maintaining their end-to-end deployment speed and eliminating duplicate filtering.

To achieve this, the researchers evaluated a hybrid approach across multiple standard benchmark datasets and visual tasks, including 2D object detection, panoptic segmentation, 3D object detection, multi-person pose estimation, and multi-object tracking. The approach adds an auxiliary one-to-many matching branch during training—assigning multiple queries to repeated ground-truth targets—to provide richer learning signals. Crucially, this auxiliary branch is discarded during deployment, ensuring that inference relies solely on the standard one-to-one branch without additional computational latency or architectural complexity.

The findings show consistent performance gains across all evaluated vision domains without slowing evaluation speeds. In 2D object detection on the COCO benchmark, the hybrid method improved the baseline model accuracy by +1.7% with a standard backbone and achieved 59.4% accuracy with a large backbone, outperforming leading existing transformer detectors. In 3D multi-view detection on the nuScenes dataset, overall detection scores rose by +1.7%, while human pose estimation and multi-object tracking saw baseline accuracy gains of +1.6%. Ablation analyses revealed that these gains stem primarily from significantly reduced localization errors and fewer missed targets, driven largely by better optimization of the shared visual feature encoder.

These results demonstrate that the limitation of detection transformers is not their core architecture, but rather an artificial data-supervision bottleneck during training. By resolving this training deficiency, teams can achieve higher model accuracy across varied computer vision tasks without increasing runtime inference cost, cloud serving latency, or engineering complexity in production pipelines.

Organizations developing or deploying transformer-based vision systems should integrate hybrid branch matching into their model training pipelines as a drop-in enhancement. For immediate implementation, teams should adopt the hybrid branch structure over alternate layer- or epoch-based variations, setting the auxiliary query repetition factor to at least four to six times the ground truth to ensure high-quality supervision signals. Future work should focus on implementing auxiliary matching calculations directly on graphics hardware to reduce remaining training-time overhead.

While the evaluation shows high confidence and consistent gains across varied model sizes and visual tasks, the primary limitation is a modest increase in training time (roughly 6% to 23%) and higher training-stage memory usage due to extra auxiliary queries. However, because memory-saving attention mechanisms can mitigate training memory and the auxiliary queries are entirely omitted during inference, the reported operational performance improvements remain robust.

Microsoft Peking University Stanford University Zhejiang University hybrid matching DETRs Hungarian matching

arXiv: 2207.13080 HDETR/H-Deformable-DETR

Paper: End-to-End Object Detection with Transformers, Nicolas Carion et al. (2020). This foundational work introduces the original DETR architecture and the one-to-one bipartite matching scheme whose training inefficiencies H-DETR directly seeks to resolve.
Paper: Deformable DETR: Deformable Transformers for End-to-End Object Detection, Xizhou Zhu et al. (2021). This work establishes Deformable DETR, which serves as one of the primary baseline architectures and benchmarked frameworks enhanced by H-DETR's hybrid matching strategy.
Paper: DAB-DETR: Dynamic Anchor Boxes are Better Queries for DETR, Shilong Liu et al. (2022). This paper presents dynamic anchor boxes for DETR query formulation, providing foundational context on query design challenges in DETR models.

Paper: DETRs Beat YOLOs on Real-time Object Detection, Yian Zhao et al. (2024). This paper advances real-time end-to-end DETR architectures, building upon the principles of efficient matching and query optimization in Transformer-based detectors.
Paper: YOLOv10: Real-Time End-to-End Object Detection, Ao Wang et al. (2024). This work extends dual label-assignment schemes combining one-to-many and one-to-one matching branches to create NMS-free real-time detectors.

Abstract

One-to-one set matching is a key design for DETR to establish its end-to-end capability, so that object detection does not require a hand-crafted NMS (non-maximum suppression) to remove duplicate detections. This end-to-end signature is important for the versatility of DETR, and it has been generalized to broader vision tasks. However, we note that there are few queries assigned as positive samples and the one-to-one set matching significantly reduces the training efficacy of positive samples. We propose a simple yet effective method based on a hybrid matching scheme that combines the original one-to-one matching branch with an auxiliary one-to-many matching branch during training. Our hybrid strategy has been shown to significantly improve accuracy. In inference, only the original one-to-one match branch is used, thus maintaining the end-to-end merit and the same inference efficiency of DETR. The method is named H-DETR, and it shows that a wide range of representative DETR methods can be consistently improved across a wide range of visual tasks, including Deformable-DETR, PETRv2, PETR, and TransTrack, among others. Code is available at: https://github.com/HDETR.

Keywords

hybrid matching DETRs Hungarian matching bipartite matching one-to-one matching end-to-end object detection auxiliary queries Deformable-DETR vision transformer

1. Introduction
2. Related work
3. Our Approach
3.1. Preliminary
3.2. Hybrid Matching
3.2.1 Hybrid Branch Scheme
3.2.2 More Variants of Hybrid Matching
4. Experiment
4.1. Improving DETR-based Approaches
4.2. Ablation Study
4.3. Comparison with State-of-the-art
5. Conclusion
References

Knowls

Knowl 1 — Hybrid one-to-one and one-to-many matching
model/method
H-DETR addresses the low training efficiency of DETR-style one-to-one assignment. In conventional DETR, Hungarian matching assigns at most one query to each ground-truth instance, so most decoder queries receive only negative classification supervision and few queries receive localization supervision.

H-DETR adds an auxiliary one-to-many matching branch during training. The original query group uses one-to-one matching and preserves DETR’s end-to-end prediction property; the auxiliary query group matches against repeated copies of each ground-truth instance, allowing several queries to receive localization supervision for the same object. The two branches are trained jointly, with masked self-attention preventing interactions between their query groups so that they can be processed in parallel.

At inference time, H-DETR discards the auxiliary branch and retains only the original one-to-one branch. Consequently, inference does not require non-maximum suppression (NMS), and the inference architecture and query count of the selected DETR baseline are retained.
Knowl 2 — Hybrid-branch training objective
equation
Let $G$ be the set of ground-truth instances in one training example, let $L$ be the number of transformer decoder layers, and let $P^l$ and $\widetilde{P}^{l}$ denote the predictions from decoder layer $l$ of the one-to-one and one-to-many branches, respectively. The one-to-one branch uses the ordinary ground-truth set $G$ :
$\mathcal{L}_{\mathrm{one2one}}=\sum_{l=1}^{L}\mathcal{L}_{\mathrm{Hungarian}}(P^l,G).$
For the one-to-many branch, every ground-truth instance is repeated $K$ times to form $\widetilde{G}=\{G^1,\ldots,G^K\}$ , where $G^1=\cdots=G^K=G$ . Hungarian matching between the auxiliary predictions and this augmented target set gives:
$\mathcal{L}_{\mathrm{one2many}}=\sum_{l=1}^{L}\mathcal{L}_{\mathrm{Hungarian}}(\widetilde{P}^{l},\widetilde{G}).$
The total training loss is
$\mathcal{L}_{\mathrm{total}}=\mathcal{L}_{\mathrm{one2one}}+\lambda\mathcal{L}_{\mathrm{one2many}},$
where $\lambda\geq 0$ weights the auxiliary loss. Each Hungarian loss follows DETR and combines classification, $L_1$ box-regression, and generalized-IoU losses. Matching is performed independently at every decoder layer.
Knowl 3 — Hybrid epoch and hybrid layer variants
model/method
H-DETR also defines two single-query-group variants of hybrid matching.

In the hybrid-epoch scheme, one query group is trained with one-to-many matching for the first fraction $\rho$ of training epochs. The ground-truth set is repeated $K_e$ times during this stage. During the remaining fraction $1-\rho$ of epochs, the same query group is trained with ordinary one-to-one matching. The query group is used directly at inference without NMS.

In the hybrid-layer scheme, one-to-many matching supervises the outputs of the first $L_1$ decoder layers, while one-to-one matching supervises the outputs of the remaining $L_2$ layers, with $L=L_1+L_2$ . Both losses are applied throughout training.

The reported settings were: hybrid branch with 300 one-to-one queries, 1500 auxiliary queries, and $K=6$ ; hybrid epoch with 1800 queries, $K_e=10$ , and $\rho=2/3$ ; and hybrid layer with 1800 queries, $K=10$ , $L_1=4$ , and $L_2=2$ . The hybrid branch was selected as the default because it provided the best training-time and inference-speed trade-off.
Knowl 4 — Consistent gains on COCO and LVIS object detection
data/table
The following results compare Deformable-DETR with its H-DETR version using the same backbone and training schedule. AP is average precision; $AP_S$ , $AP_M$ , and $AP_L$ are AP for small, medium, and large objects. H-DETR improves every listed configuration.
Could not parse LaTeX table
The COCO AP gains range from $+0.8$ to $+1.7$ points across backbones and schedules, while the LVIS gains are $+1.3$ points with ResNet-50 and $+0.9$ points with Swin-L.
Knowl 5 — Generalization to segmentation, pose estimation, 3D detection, and tracking
data/table
The hybrid matching strategy transfers to DETR-based tasks whose queries represent masks, human poses, 3D objects, or tracks. The reported representative comparisons are:
Could not parse LaTeX table
For the nuScenes comparison, mAP also increases from $41.07$ to $42.59$ . For MOT17 validation, the false-negative count decreases from $15680$ to $13657$ , while IDF1 increases from $68.1$ to $68.3$ . On COCO pose estimation, the Swin-L result increases from $73.3$ AP to $74.9$ AP, and the ResNet-101 result increases from $69.9$ AP to $71.0$ AP. These results support the paper’s claim that the matching modification is not specific to 2D bounding-box detection.
Knowl 6 — Hybrid branch is the most favorable matching variant
data/table
Ablations on a two-stage Deformable-DETR baseline compare the three hybrid schemes under matched query and positive-sample budgets. AP is reported after 12, 24, and 36 training epochs; inference GFLOPs and inference FPS are measured on the same V100 GPU.
Could not parse LaTeX table
All three hybrid schemes outperform their corresponding conventional baselines. The hybrid branch reaches the same 6.7 FPS as the 300-query baseline and has the lowest average training time among the hybrid variants, whereas the epoch and layer schemes evaluate 1800 queries and therefore have lower inference speed.
Knowl 7 — Effect of auxiliary replication, query count, and parameter sharing
data/table
On COCO 2017 validation with a 12-epoch two-stage Deformable-DETR baseline, the default hybrid branch uses $K=6$ repeated ground-truth copies and $T=1500$ auxiliary queries. The number of auxiliary queries is set to $T=300K$ in the replication experiment.
Could not parse LaTeX table
With $K=6$ , changing the auxiliary query count $T$ gives AP values $47.8$ , $48.3$ , $48.4$ , $48.4$ , $48.7$ , and $48.6$ for $T=300$ , $600$ , $900$ , $1200$ , $1500$ , and $1800$ , respectively. Thus, the reported default $K=6$ , $T=1500$ is near the best tested setting; gains become consistent when $K$ exceeds 3.

Parameter-sharing ablations give AP values of $48.7$ when the encoder, decoder, box head, and classification head are all shared; $48.6$ when only the classification head is independent; $48.5$ when both prediction heads are independent; $48.3$ when the decoder and both heads are independent; and $47.3$ when encoder, decoder, and heads are all independent. The results indicate that retaining a shared transformer encoder is particularly important for the reported performance.
Knowl 8 — Hybrid matching improves localization and false-negative errors
empirical result
A component ablation on COCO 2017 validation under 12 training epochs starts from a two-stage Deformable-DETR with AP $43.3$ . Increasing the feed-forward-network dimension gives AP $43.7$ ; additionally setting transformer dropout to zero gives $44.3$ ; adding mixed query selection gives $46.3$ ; adding the look-forward-twice refinement gives $47.0$ ; and finally adding hybrid matching gives $48.7$ .

The paper’s localization-error analysis reports the following changes from Deformable-DETR to H-Deformable-DETR: AP increases from $47.0$ to $48.7$ , overall oLRP decreases from $62.6$ to $61.2$ , oLRP for localization errors decreases from $13.8$ to $13.3$ , and oLRP for false negatives decreases from $41.0$ to $39.4$ . Since lower oLRP is better, the results attribute the improvement mainly to more accurate localization of matched detections and fewer unmatched ground-truth instances.
Knowl 9 — System-level COCO result with a Swin-L backbone
empirical result
With single-scale evaluation, a Swin-L backbone, $1333\times800$ input resolution, and 36 training epochs, H-Deformable-DETR obtains $59.4$ AP on COCO validation. Its detailed scores are $77.8$ AP $_{50}$ , $65.4$ AP $_{75}$ , $43.1$ AP for small objects, $63.1$ AP for medium objects, and $74.2$ AP for large objects.

Under the same reported framework, backbone, input size, and schedule, the comparison systems Group-DETR and DINO-DETR obtain $58.4$ and $58.5$ AP, respectively. The H-Deformable-DETR result is the strongest among the listed single-scale systems, although it includes additional enhancement techniques used in the corresponding system-level comparison.
Knowl 10 — Inference efficiency is preserved, but training and memory costs increase
limitation
The principal deployment advantage of H-DETR is preserved because only the one-to-one branch is evaluated. On COCO with the reported Deformable-DETR setup, the one-to-one branch gives AP values $48.7$ , $49.9$ , and $50.0$ at 12, 24, and 36 epochs without NMS, at 6.7 FPS and 80 minutes of average training time. Using only one-to-many predictions without NMS is ineffective, giving AP values $13.5$ , $13.1$ , and $12.9$ ; applying NMS restores AP to $48.6$ , $49.8$ , and $49.9$ but reduces inference speed to 5.4 FPS. Training only with one-to-many matching and using NMS reaches $49.4$ , $50.2$ , and $48.8$ AP, but requires 95 minutes and 5.3 FPS.

The auxiliary branch is not free during training. With ResNet-50, increasing from 300 baseline queries to the default 300 one-to-one plus 1500 auxiliary queries increases computation from 268.19 to 282.39 GFLOPs, training time from 65 to 80 minutes, and GPU memory from 5480 MB to 7728 MB. With Swin-L, the corresponding values increase from 912.29 to 926.48 GFLOPs, 202 to 215 minutes, and 8955 MB to 11203 MB. The paper attributes most memory growth to naive self- and cross-attention and most training-time growth to CPU Hungarian matching and cost/loss computation; optimized attention implementations and GPU matching are suggested as ways to reduce these overheads.

Coverage note — The supplementary-only full panoptic-segmentation table and additional loss-curve, precision-recall, and query-selection ablations were omitted because the main paper provides only summary statements for them and they are secondary to the core hybrid-matching method and its principal evaluations.
